XYZ KMX 1500
XYZ KMX 1500
Spindle: 2.25 kW (3hp) Variable Speed Head
Table Size: 1,069 x 228mm
Travels: 595 x 300mm
Standard Equipment
- Vari Speed 2 Range Head.
- 3 Axis DRO.
- 2 Axis CNC.
- Verify Solid Model Graphics.
- Precision Ground Ballscrews.
- Coolant.
- Work Light.
- Auto Lubrication.
- Steel Swarf Tray.
- Interlocked Guarding.
Optional Equipment
- TRAKing® including Electronic Handwheels.
- Riser Blocks.
- Air Power Drawbar.
- 4th Axis DRO.
- Offline Software.
- Tooling, Vices etc.
- Parasolid Converter.
- DXF Converter.
- Millstar (Quill DRO).
Call 01823 674200 for more details.
Watch The Videos Below
KMX Range of Turret Milling Machines
Introducing the RMX, RLX & KMX controls
KMX CONTROL
THE BEST LOW VOLUME CONTROL MADE EVEN BETTER
Machine Features
Motor / Head
All Turret Mill spindles are driven by AC motors transmitting power through a two speed gear box and variable speed cone pulleys. Precision quill bearings are dynamically balanced and built in a dust free, temperature controlled environment, to ensure smooth and accurate cutting performance.
TRAKing®
KMX Turret Mills have the TRAKing facility as an option which allows the operator to wind the handwheel and the machine moves through the program at that speed. The faster you wind the faster it machines. Stop or reverse the hand wheel and the machine does the same.
Servo’s & Ballscrews
High performance servo motors are built into the casting to protect them from the harsh machine shop environment. These servo’s provide smooth consistent power to the precision ground ballscrews to give a perfect milled finish.
Manual Operation
Mechanical handwheels allow the machinist to ‘feel’ the cutting process when manual machining is preferred, and will automatically disengage when the machine is running under CNC control.
Solid Casting
Built of solid Meehanite ribbed cast iron with induction hardened and ground slides. Turcite-B coated ways and auto lubrication to all slides and precision ground ballscrews aid accuracy and longevity.
Control
The latest generation of ProtoTRAK KMX control provides maximum operator productivity particularly on one-off components or small batches. Even an operator with no previous CNC experience will be producing simple or complex parts within hours.
Specification
| XYZ KMX 1500 | XYZ KMX 2000 | XYZ KMX SLV | |
|---|---|---|---|
| Spindle | 2.25 kW (3hp) Variable Spindle Speed | 2.25 kW (3hp) Variable Spindle Speed | 3.75 kW (5hp) Variable Spindle Speed |
| Spindle Speeds | 50 - 3,500 rpm | 60 - 4,200 rpm | 70 - 3,600 rpm |
| 2 Speed Ranges | (50 - 400 & 420 - 3,500 rpm) | (60 - 500 & 500 - 4,200 rpm) | (70 - 460 & 500 - 3,600 rpm) |
| Table Size | 1,069 x 228mm | 1,270 x 254mm | 1,473 x 305mm |
| T Slot Size | 16mm | 16mm | 16mm |
| T Slots | 3 off | 3 off | 3 off |
| X Axis Table Travel | 595mm | 745mm | 1,000mm |
| Y Axis Table Travel | 300mm | 370mm | 396mm |
| Knee Vertical Travel | 358mm | 406mm | 394mm - Powered |
| Slideway Type | Hardened Way | Hardened Chrome | Hardened & Ground Boxway |
| Ram Travel | 390mm | 450mm | 450mm |
| Spindle Taper | R8 (ISO30 Optional) | R8 (ISO30 Optional) | ISO 40 |
| Quill Power Feeds | .038 .076 .15mm | .038 .076 .15mm | .038 .076 .15mm |
| No of Quill Feeds | 3 | 3 | 3 |
| Quill Diameter | 86mm | 86mm | 105mm |
| Quill Travel | 127mm | 127mm | 127mm |
| Max Table Load | 350 kg | 350 kg | 580 kg |
| Swivel on Turret | 360° | 360° | 360° |
| Head Tilt Front to Back | +45° / -45° | +45° / -45° | +45° / -45° |
| Head Tilt Left to right | +90° / -90° | +90° / -90° | +90° / -90° |
| Max Throat Depth | 686mm | 686mm | 700mm |
| Machine Weight | 1,250Kg | 1,350Kg | 1,850Kg |
| Footprint (without travels) | 1,600 x 1,670 x 2,185mm | 1,880 x 1,750 x 2,220mm | 2,173 x 2,035 x 2,350mm |
| Floorplan (includes table travels) | 2,220 x 1,670 x 2,185mm | 2,621 x 1,902 x 2,220mm | 3,176 x 2,035 x 2,350mm |
| Working Height (without riser blocks) | 2,220mm | 2,175mm | 2,330mm |
| Power Requirements | 8A | 10A | 18A |
| Air Requirements | 6 bar (220 L/min) | 6 bar (220 L/min) | 6 bar (220 L/min) |
| XYZ KMX 1500 | |
|---|---|
| Spindle | 2.25 kW (3hp) Variable Spindle Speed |
| Spindle Speeds | 50 - 3,500 rpm |
| 2 Speed Ranges | (50 - 400 & 420 - 3,500 rpm) |
| Table Size | 1,069 x 228mm |
| T Slot Size | 16mm |
| T Slots | 3 off |
| X Axis Table Travel | 595mm |
| Y Axis Table Travel | 300mm |
| Knee Vertical Travel | 358mm |
| Slideway Type | Hardened Way |
| Ram Travel | 390mm |
| Spindle Taper | R8 (ISO30 Optional) |
| Quill Power Feeds | .038 .076 .15mm |
| No of Quill Feeds | 3 |
| Quill Diameter | 86mm |
| Quill Travel | 127mm |
| Max Table Load | 350 kg |
| Swivel on Turret | 360° |
| Head Tilt Front to Back | +45° / -45° |
| Head Tilt Left to right | +90° / -90° |
| Max Throat Depth | 686mm |
| Machine Weight | 1,250Kg |
| Footprint (without travels) | 1,600 x 1,670 x 2,185mm |
| Floorplan (includes table travels) | 2,220 x 1,670 x 2,185mm |
| Working Height (without riser blocks) | 2,220mm |
| Power Requirements | 8A |
| Air Requirements | 6 bar (220 L/min) |
