XYZ PROTURN RLX 1630
XYZ PROTURN RLX 1630
SWING OVER BED 400mm
SPINDLE BORE 54mm
DISTANCE BETWEEN CENTRES 760mm
MAX 2500 RPM
Standard Equipment
- TRAKing®.
- Constant Surface Speed.
- Verify Solid Model Graphics. Rapid
- Traverse with Joy Stick.
- 3 Jaw Chuck 200mm.
- Quick Change Toolpost and 6 Holders.
- Centres and Bushes.
- Tailstock.
- Interlocked Chuck Guard and Main Guard.
- Auto Lubrication.
- Coolant.
- Worklight.
Optional Equipment
- 4 Station Auto Indexing Toolpost.
- Faceplates, Steadies, Chucks and Collet Chucks.
- Offline Software.
- Adjustable Back Stop.
- DXF Converter.
BETTER
New Hardware, Faster Feeds,
24 NEW features.
EASIER
Now with 15.6” touch screen.
FASTER
Drawing to finished component much faster than before.
A closer look at the RLX 1630
Introducing: The ProtoTRAK RX
TRAKing on XYZ ProTURN Lathes
Specification
| XYZ RLX 1630 | XYZ RLX 355 | XYZ RLX 425 x 1.25m / 2m | XYZ RLX 555 x 1m / 1.75m | XYZ RLX 555 x 3m | XYZ RLX 780 x 3m | |
|---|---|---|---|---|---|---|
| Spindle | 7.5 hp Variable Spindle Speed with Inverter Drive | 7.5 hp Variable Spindle Speed with Inverter Drive | 10 hp Variable Spindle Speed with Inverter Drive | 15 hp Variable Spindle Speed with Inverter Drive | 15 hp Variable Spindle Speed with Inverter Drive | 40 hp Variable Spindle Speed with Inverter Drive |
| Spindle Speeds | 150 - 2,500 rpm | 50 - 4,000 rpm | 25 - 2,500 rpm | 30 - 1,800 rpm | 30 - 1,800 rpm | 20 - 1300 rpm |
| Spindle Bore | 54 mm | 52 mm | 80 mm | 104 mm | 104 mm | 160 mm |
| Spindle Nose | D1-6 Camlock | D1-6 Camlock | D1-8 Camlock | D1-11 Camlock | D1-11 Camlock | A2-11 |
| Speed Ranges | Single Range 150 - 2,500 rpm | 2 Ranges High 100 - 4,000 rpm / Low 50 - 1,410 rpm | 3 Ranges High 140 - 2,500 rpm / Med 50 - 850 rpm / Low 25 - 300 rpm | 2 Ranges High 140 - 1,800 rpm / Low 30 - 375 rpm | 2 Ranges High 140 - 1,800 rpm & Low 30 - 375 rpm | 2 Ranges High 40 - 1300 rpm & Low 20 - 415 rpm |
| Spindle Taper | MT4 in bush | MT4 in bush | MT7 in bush | MT7 in bush | MT7 in bush | MT7 in bush |
| Swing Over Bed | 400 mm | 360 mm | 480 mm | 560 mm | 560 mm | 780 mm |
| Swing in Gap | N/A | N/A | 700 mm | 780 mm | 900 mm | 1090 mm |
| Gap in front of Faceplate | N/A | N/A | 170 mm | 227 mm | 210 mm | 157 mm |
| Swing over Cross Slide | 218 mm | 225 mm | 257 mm | 350 mm | 350 mm | 535 mm |
| Cross Slide Travel | 216 mm | 185 mm | 230 mm | 280 mm | 375 mm | 430 mm |
| Distance between Centres | 760 mm | 1000 mm | 1250 mm / 2000 mm | 1000 mm / 1750 mm | 3000 mm | 3000 mm |
| Maximum Cutting Length | 760 mm | 900 mm | 1080 mm / 1900 mm | 900 mm / 1650 mm | 2900 mm | 2900 mm |
| Tailstock Travel | 127 mm | 150 mm | 160 mm | 160 mm | 200 mm | 200 mm |
| Tailstock Taper | MT4 | MT4 | MT5 | MT5 | MT6 | MT6 |
| Tailstock Diameter | 60 mm | 60 mm | 75 mm | 90 mm | 105 mm | 105 mm |
| Bed Width | 320 mm | 300 mm | 370 mm | 370 mm | 500 mm | 500 mm |
| Ballscrews | X & Z | X & Z | X & Z | X & Z | X & Z | X & Z |
| Servo Motors | X & Z | X & Z | X & Z | X & Z | X & Z | X & Z |
| Floorplan (L x D x H) | 2090 x 1200 x 1800 mm | 2300 x 1370 x 1810 mm | 2600 x 1480 x 1830 mm / 3460 x 1480 x 1830 mm | 2600 x 1600 x 1910 mm / 3450 x 1600 x 1910 mm | 5400 x 2010 x 1840 mm | 5400 x 2300 x 2100 mm |
| Machine Weight | 1550 kg | 1930 kg | 2700 kg / 3700 kg | 3200 kg / 4100 kg | 6600 kg | 8,600 kg |
| Power Requirements | 27A | 27A | 33A | 42A | 43A | 54A |
| Air Requirements | No Air Required | 6 bar (220 L/min) | 6 bar (220 L/min) | 6 bar (220 L/min) | 6 bar (220 L/min) | 6 bar (220 L/min) |
| XYZ RLX 1630 | XYZ RLX 780 x 3m | |
|---|---|---|
| Spindle | 7.5 hp Variable Spindle Speed with Inverter Drive | 40 hp Variable Spindle Speed with Inverter Drive |
| Spindle Speeds | 150 - 2,500 rpm | 20 - 1300 rpm |
| Spindle Bore | 54 mm | 160 mm |
| Spindle Nose | D1-6 Camlock | A2-11 |
| Speed Ranges | Single Range 150 - 2,500 rpm | 2 Ranges High 40 - 1300 rpm & Low 20 - 415 rpm |
| Spindle Taper | MT4 in bush | MT7 in bush |
| Swing Over Bed | 400 mm | 780 mm |
| Swing in Gap | N/A | 1090 mm |
| Gap in front of Faceplate | N/A | 157 mm |
| Swing over Cross Slide | 218 mm | 535 mm |
| Cross Slide Travel | 216 mm | 430 mm |
| Distance between Centres | 760 mm | 3000 mm |
| Maximum Cutting Length | 760 mm | 2900 mm |
| Tailstock Travel | 127 mm | 200 mm |
| Tailstock Taper | MT4 | MT6 |
| Tailstock Diameter | 60 mm | 105 mm |
| Bed Width | 320 mm | 500 mm |
| Ballscrews | X & Z | X & Z |
| Servo Motors | X & Z | X & Z |
| Floorplan (L x D x H) | 2090 x 1200 x 1800 mm | 5400 x 2300 x 2100 mm |
| Machine Weight | 1550 kg | 8,600 kg |
| Power Requirements | 27A | 54A |
| Air Requirements | No Air Required | 6 bar (220 L/min) |
Machine Features
Control
The latest generation of ProtoTRAK RLX control provides maximum operator productivity particularly on one-off components or small batches. Even an operator with no previous CNC experience will be producing simple or complex parts within hours.
Tailstock
Heavy tailstock with two clamp points prevents movement when machining components between centres. Repostioning is effortless and is achieved by providing an air cushion that lifts the tailstock from the bed (not on the XYZ ProTURN RLX 1630).
Guarding
Built and guarded to comply with the latest CE regulations to ensure complete operator safety. When closed and in full CNC operation the easy lift, totally enclosed guard, ensures water tight containment of swarf and coolant.
Saddle & Apron
The apron moves with the saddle and emulates the actions of a manual lathe. This brings reassuring familiarity to the first time user of a CNC Lathe, and a joy stick provides for rapid positioning.
Headstock
The headstock is built using Japanese induction hardened and precision ground gears. Two precision taper roller bearings and a support journal bearing ensure spindle rigidity and concentricity. High pressure oil lubrication is provided to all gears and bearings via a pump and oil cooler ensuring thermal stability, quiet running and long life.
Swarf Tray
Front opening easy access Swarf Tray makes light work of swarf removal and reduces the amount of space required at the rear of the machine.
TRAKing®
Proturn Lathes are standard with TRAKing which allows the operator to wind the handwheel and the machine moves through the program. The faster you wind the faster it machines. Stop or reverse the handwheel and the machine does the same.
Cast Bed Base
Unlike most other Lathes that are cast or fabricated in two or three pieces and then bolted together, the Proturn RLX is a one piece solid ribbed casting that provides weight and rigidity ensuring unrivalled precision. The extra wide ‘Vee and flat’ bed way provides a large bearing surface that makes other Lathes seem flimsy by comparison. The lower cost RLX 1630 does not have a single piece casting.
